JBL 杰宝JBL OlympusS7R/S8R

上市参考售价:¥24,950

推出年代:1973

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%
(S7R):
 1973年 -¥21500/个
 1975年-¥24950/个
(S8R):
 1973年 -¥28280/个
 1975年 -¥30500/个

器材规格

The specification of S7R
Scheme 2 ways, 2 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For high regions: Horn type (LE85+HL91)
Passive radiator: 38cm cone type (PR15)
Network: LX5
Cross over frequency 500Hz
Impedance 8ohms
Sound pressure level 95dB (new Japanese Industrial Standard)
Allowable input 100W (succession special NetWare program)
Dimensions Width 1020x height 670x depth of 510mm
Weight 74kg


The specification of S8R
Scheme 3 ways, 3 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For mid ranges: Horn type (375+HL93)
For high regions: Direct radiator (075)
Passive radiator: 38cm cone type (PR15)
Network: LX5, N7000
Cross over frequency 500Hz, 7000Hz
Impedance 8ohms
Sound pressure level 95dB (new Japanese Industrial Standard)
Allowable input 125W (succession special NetWare program)
Dimensions Width 1020x height 670x depth of 510mm
Weight 82kg
