器材规格
SPECIFICATIONS:
Power Output:
100W x 2 with 24,000uF of capacitance using 200W SMPS
325W peak power at 8 ohms.
Freq. Response: 20 Hz -0.3dB to 120 kHz -3dB
THD+N = 0.01%, 1kHz, 10W, 4 ohm load
Input sensitivity for 1W @ 8 ohms = 400mV
Input impedance at 1kHz = 2K ohms
Remote input selection and volume control with memory (last selection, volume level)
Digitally-controlled switched attenuator. Volume Range: +30dB to -70dB with 0.5dB steps
Audio Inputs:
4 sets of RCA inputs (1 set can be configured as pre-out)
Audio Outputs:
1 set of RCA preamp output jacks (only 3 sets of RCA inputs are available if this is configured)
Speaker Binding Posts accept spade lugs or banana plugs
Chassis is 100% high-grade, brushed and anodized aluminum to reduce audio resonance
Dimensions: 1.75"H x 8.5"W x 16"D
Weight: 9 lbs.
Power Output:
100W x 2 with 24,000uF of capacitance using 200W SMPS
325W peak power at 8 ohms.
Freq. Response: 20 Hz -0.3dB to 120 kHz -3dB
THD+N = 0.01%, 1kHz, 10W, 4 ohm load
Input sensitivity for 1W @ 8 ohms = 400mV
Input impedance at 1kHz = 2K ohms
Remote input selection and volume control with memory (last selection, volume level)
Digitally-controlled switched attenuator. Volume Range: +30dB to -70dB with 0.5dB steps
Audio Inputs:
4 sets of RCA inputs (1 set can be configured as pre-out)
Audio Outputs:
1 set of RCA preamp output jacks (only 3 sets of RCA inputs are available if this is configured)
Speaker Binding Posts accept spade lugs or banana plugs
Chassis is 100% high-grade, brushed and anodized aluminum to reduce audio resonance
Dimensions: 1.75"H x 8.5"W x 16"D
Weight: 9 lbs.
