4343-¥28000
4343WX-¥29000
4343WX-¥29000
器材规格
Scheme 4 ways, 4 loudspeaker bass-reflex scheme, and a bookshelf type
Unit For low-pass: 38cm cone type (2231A)
For inside low-pass: 25cm cone type (2121)
For mid-high ranges: Horn type (2308+2307+2420)
For high [ super-] regions: Horn type (2405)
Play frequency band 35Hz - 20kHz
Cross over frequency 300Hz, 1250Hz, 9500Hz
Directivity 60 degrees x 30 degrees (16kHz)
Impedance 8ohms
Output sound pressure level 93dB (new Japanese Industrial Standard)
Allowable input (RMS) At the time of a network: 75W
300Hz or less: 75W
300Hz or more: 75W
Enclosure dimension Woofer: 156L
Mid Woofer: 14L
Dimensions Width 635x height 1051x depth of 435mm
Weight 79kg
Option Channel divider 5234 (120,000yen)
Filter substrate 52-5140 (5,000yen)
Unit For low-pass: 38cm cone type (2231A)
For inside low-pass: 25cm cone type (2121)
For mid-high ranges: Horn type (2308+2307+2420)
For high [ super-] regions: Horn type (2405)
Play frequency band 35Hz - 20kHz
Cross over frequency 300Hz, 1250Hz, 9500Hz
Directivity 60 degrees x 30 degrees (16kHz)
Impedance 8ohms
Output sound pressure level 93dB (new Japanese Industrial Standard)
Allowable input (RMS) At the time of a network: 75W
300Hz or less: 75W
300Hz or more: 75W
Enclosure dimension Woofer: 156L
Mid Woofer: 14L
Dimensions Width 635x height 1051x depth of 435mm
Weight 79kg
Option Channel divider 5234 (120,000yen)
Filter substrate 52-5140 (5,000yen)
