Le Son LS001网络解码播放器提供丰富的数码接口,包括USB和LAN网络、蓝牙无线等接口,装载专门开发的针对网络数码传输而优化的异步数据处理组件,支持UPnP 的 AV 2.0 / DLNA标准,支持高清PCM和DSD音频、WAV, AIFF, FLAC,ALAC, MP3, AAC, WMA,DSF,DFF等格式,PCM模式下支持192kHz 24-bit解码播放、DSD支持1-bit 2.8224MHz解码。对应USB和LAN接入实现完美的数据传输和无抖动的解码播放,配备完美的超高精度时钟,具有出色的相位噪声特性。4个DAC双单声道全平衡处理,16倍过采样配合最小相位失真的滤波器。系统采用了超过30个分组超低噪音的电源供应,全分立式A级无反馈放大输出、高性能耳机输出。
器材规格
Technical data:
Size : 426 x 320 x 90 mm / 16,8 x 12,6 x 3,5 ‘’
Weight : 13,1 kg / 28,9 lbs
Power consumption: standby <1W / operation <30W
Control & firmware update:
- USB-A port for memory stick
- Bluetooth
Network streaming:
- RJ45 connector for wired LAN
- UPnP™ AV 2.0 / DLNA
- asychronous, jitter-free and bit-perfect audio data transmission
- supported formats: WAV, AIFF, FLAC, ALAC, MP3, AAC, WMA, DSF, DFF
- PCM/DXD up to 384kHz 32-bit
- DSD 1-bit at 2.8224MHz (DSD64), 1-bit at 5.6448MHz (DSD128)
USB streaming:
- USB-B port
- Audio Class 2.0 (drivers for Windows provided)
- asychronous, jitter-free and bit-perfect audio data transmission
- PCM up to 192kHz 24-bit
- DSD (via DoP) 1-bit at 2.8224MHz
Digital audio inputs:
- optical S/PDIF on Toslink
- balanced AES/EBU on XLR (110Ω input impedance)
- coaxial S/PDIF on RCA (75Ω input impedance)
- I2S on HDMI connector
Optional use Inputs:
- external clock input on BNC (75Ω input impedance)
- external power supply input on LEMO connectors
Analog outputs:
- unbalanced RCA : 3.0V RMS (75Ω output impedance)
- balanced XLR : 6.0V RMS (150Ω output impedance)
- headphones : 3.0V RMS (2,7Ω output impedance)
Frequency response:
- +/- 0.1dB : DC to 20kHz
Signal to noise ratio:
- SNR (A-weighted) : >120dB
Total harmonic distortion:
THD + N, 0dBFS, 24-bit : <0.001%
Size : 426 x 320 x 90 mm / 16,8 x 12,6 x 3,5 ‘’
Weight : 13,1 kg / 28,9 lbs
Power consumption: standby <1W / operation <30W
Control & firmware update:
- USB-A port for memory stick
- Bluetooth
Network streaming:
- RJ45 connector for wired LAN
- UPnP™ AV 2.0 / DLNA
- asychronous, jitter-free and bit-perfect audio data transmission
- supported formats: WAV, AIFF, FLAC, ALAC, MP3, AAC, WMA, DSF, DFF
- PCM/DXD up to 384kHz 32-bit
- DSD 1-bit at 2.8224MHz (DSD64), 1-bit at 5.6448MHz (DSD128)
USB streaming:
- USB-B port
- Audio Class 2.0 (drivers for Windows provided)
- asychronous, jitter-free and bit-perfect audio data transmission
- PCM up to 192kHz 24-bit
- DSD (via DoP) 1-bit at 2.8224MHz
Digital audio inputs:
- optical S/PDIF on Toslink
- balanced AES/EBU on XLR (110Ω input impedance)
- coaxial S/PDIF on RCA (75Ω input impedance)
- I2S on HDMI connector
Optional use Inputs:
- external clock input on BNC (75Ω input impedance)
- external power supply input on LEMO connectors
Analog outputs:
- unbalanced RCA : 3.0V RMS (75Ω output impedance)
- balanced XLR : 6.0V RMS (150Ω output impedance)
- headphones : 3.0V RMS (2,7Ω output impedance)
Frequency response:
- +/- 0.1dB : DC to 20kHz
Signal to noise ratio:
- SNR (A-weighted) : >120dB
Total harmonic distortion:
THD + N, 0dBFS, 24-bit : <0.001%
