Form Integrated stereo amplifier
Rated continuation average output
(both channel operation, 20Hz - 20kHz) 110 W/ch (4ohms)
100 W/ch (6ohms)
80 W/ch (8ohms)
THD (both channel operation) 0.04%
IM distortion 0.01%
Frequency response
(at the time of a rated continuation average output) High Level input: 20Hz-20kHz+0 -0.2dB
Low Level input: 20Hz-20kHz+0.2 -0.5dB
Dumping factor 110 (8-ohm load, 50Hz)
Input sensitivity
(an Output power / EIA1W output)/impedance AD input(MC): 0.201mV/22.5 microvolt/100 ohms
AD input(MM): 7.0mV/780microvolt/47kohm
High Level input: 201mV/22.5mV/20kohm
Balanced input: 201mV/22.5mV/40kohm
The Disc maximum input
(Rec out, 1kHz, 0.005% of distortion) MM:250mVrms
MC:7.0mVrms
An Output voltage/impedance
(at the time of a rated continuation average output) Tape Rec output: 200mV/200 ohms (AD)
Gain High Level input -> Output: 42dB
AD input (MM) -> Tape rec output: 29dB
AD input (MC) -> Tape rec output: 60dB
S/N, input conversion noise
Input short-circuit and A-compensation EIA S/N
At the time of a rated
input S/N Input conversion noise
High Level input: 113dB -127dBV 83dB
Balanced input: 94dB -108dBV 83dB
AD input(MM): 92dB -135dBV 82dB
AD input(MC): 78dB -152dBV 81dB
Subsonic Filter 25Hz, -12 dB/oct
Load impedance 4ohm-16ohm
Headphone jack Conformity impedance: 4ohms - 100ohms
Power source AC100V, 50Hz/60Hz
Power consumption 35W (at the time of E-210 and no inputting)
37W (at the time of E-210A and no inputting)
190W (Electrical Appliance and Material Control Law)
315W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 150x depth of 417mm
Weight 18.0kg
Attachment: Remote commander RC-15
Remote control system Infrared pulse system
Power source DC 3V
Dry cell AA (SUM-3/R6), two pieces
The maximum Dimensions Width 45x height 136x depth of 18mm
Weight 85g(Battery Includid)
