S607(S7R):1973 年 ¥21500
S608(S8R): 1973 年 ¥ 27845
S608(S8R): 1973 年 ¥ 27845
器材规格
The specification of S7R
Scheme 2 ways, 2 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For high regions: Horn type (LE85+HL91)
Passive radiator: 38cm cone type (PR15)
Network: LX5
Cross over frequency 500Hz
Impedance 8ohms
Allowable input 100W (succession special NetWare program)
Dimensions Width 980x height 670x depth of 510mm
Weight 86kg
The specification of S8R
Scheme 3 ways, 3 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For mid ranges: Horn type (375+HL93)
For high regions: Direct radiator (075)
Passive radiator: 38cm cone type (PR15)
Network: LX5, N7000
Cross over frequency 500Hz, 7000Hz
Impedance 8ohms
Allowable input 125W (succession special NetWare program)
Dimensions Width 980x height 670x depth of 510mm
Weight 99kg
Scheme 2 ways, 2 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For high regions: Horn type (LE85+HL91)
Passive radiator: 38cm cone type (PR15)
Network: LX5
Cross over frequency 500Hz
Impedance 8ohms
Allowable input 100W (succession special NetWare program)
Dimensions Width 980x height 670x depth of 510mm
Weight 86kg
The specification of S8R
Scheme 3 ways, 3 loudspeaker passive radiator scheme, and a floor type
Unit etc. For low-pass: 38cm cone type (LE15A)
For mid ranges: Horn type (375+HL93)
For high regions: Direct radiator (075)
Passive radiator: 38cm cone type (PR15)
Network: LX5, N7000
Cross over frequency 500Hz, 7000Hz
Impedance 8ohms
Allowable input 125W (succession special NetWare program)
Dimensions Width 980x height 670x depth of 510mm
Weight 99kg
