Accuphase金嗓子 金嗓子Kensonic Accuphase C-200

上市参考售价:¥7,750

推出年代:1973.8

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%

器材规格

Form Accuphase stereo control amplifier
Frequency response High-level input: 20Hz - 20000Hz, and +0 -0.2 dB
DISC and a Media-Interface-Connector input: 20Hz - 20000Hz, ±0.2dB
THD 0.05% or less (for 20Hz - 20000Hz and by Output power)
Input sensitivity/input impedance DISC1:2-6mV/20kohm, 30kohm, 47kohm
DISC2:2-6mV/47kohm
Media-Interface-Connector: 2mV/47kohm
Tuner: 200mV/130kohm
AUX1, 2, Front:200mV/130kohm
Tape Play1, 2, Front:200mV/130kohm
An Output power/Output load impedance Main Output: 2.0V/200 ohm
Headphones: 0.4V/0.3 ohm (in volume control maximum and the rated input)
Tape Rec Output1, 2, Front: 200mV/200 ohms (at the time of a DISC input)
Mono Output: 0.42V/38kohm
Maximum-except-take-off level More than 10V (distortion 0.05%)
The disc maximum input 400mV - 1.2Vrms (1kHz, 0.05% of distortion)
* 400mV is the DISC level-control maximum (equalizer gain 40dB).
※1. 2V is the DISC level-control minimum (equalizer gain 30dB).
Gain Tuner, AUX, and a Tape Play input
Tape Rec Output:
Main Output:
Headphone: 0dB
20dB
6dB DISC1, 2, and a Media Interface Connector input
Tape Rec Output:
Main Output:
Headphone: 40dB
60dB
46dB
S/N (an Output power, volume control maximum) Tuner, AUX, Tape Play: 90dB or more (rated input)
DISC, Media Interface Connector: 74dB or more (10mV input)
Volume control linkage error Less than 1dB
Tone control
Low-pass : Changing point 400Hz :
200Hz: ±10dB (100Hz)
±10dB (50Hz)
High region : Changing point 2.5kHz :
5kHz: ±10dB (10kHz)
±10dB (20kHz)
DISC low enhancement (massive compensation circuit) They are 0dB, +0.5dB, and +1dB (100Hz) to the RIAA standard characteristic.
Compensation (volume control-30dB) 50Hz:+10dB
Filter DISC Subsonic Filter: 25Hz, 6 dB/oct
A low filter: 30Hz, 12 dB/oct
A high filter: 5kHz, 12 dB/oct
The semiconductor used Transistor: 80
Diode: 35
Power source 100V, 117V, 220V, 240V, 50Hz/60Hz
Power consumption 36W
Dimensions Width 445x height 152x depth of 355mm
Weight 14kg
