Accuphase金嗓子 金嗓子Accuphase C-240

上市参考售价:¥19,750

推出年代:1978.9

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%

器材规格

Form Stereo control center
Frequency response High-level input: It is +0 20Hz - 20000Hz. -0.2 dB
Disc input: 20Hz-20000Hz±0.2dB
THD 0.005% (for 20Hz - 20kHz, Output power)
Input sensitivity/input impedance DISC1, 2 (Head Amp OFF):2.0mV/100 ohm, 47kohm, 82kohm, a 150kohm change
DISC1, 2 (Head Amp ON):0.1mV/100ohm fixation
Tuner, AUX, Tape Play1, 2:126mV/50kohm
An Output power/Output load impedance
(Volume maximum, the rated input) Output: 2.0V/2 ohm
Tape Rec1, 2:126mV/500 ohms
Headphone Output load impedance: 0.3ohm
Output (8ohm load): 0.25W, 1kHz, 0.01% of distortion
Maximum-except-take-off level (for 20Hz - 20kHz) More than 10V, 0.005% of distortion
The disc maximum input Head Amp OFF: 400mVrms, 1kHz, 0.005% of distortion
Head Amp ON: 20mVrms, 1kHz, 0.005% of distortion
Minimum load impedance Outputs: 1kohm
Tape Rec: 10kohm
Gain
Tuner, AUX, and Tape Play
Tape Rec: 0dB
Outputs: 24dB
HeadPhones: 20dB
DISC (Head Amp OFF)
Tape Rec: 36dB
Outputs: 60dB
HeadPhones: 56dB (It is +26dB at the time of the DISC input HEAD AMP ON)
S/N / Input conversion noise
(at the time of input short-circuit, IHF-A, and a rated input) High-level input: 110dB / -128dBV
Disc input (Head Amp OFF): 85dB / -139dBV
Disc input (Head Amp ON): 72dB / -152dBV
Tone control The change type by 8 step push switch
Low-pitched sound 500Hz : ±8dB (50Hz)
200Hz : ±8dB (20Hz) 2dB step
2dB step
Loud sound 2kHz : ±8dB (20kHz)
7kHz : ±8dB (50kHz) 2dB step
2dB step
Loudness Compensation COMP1:+6dB(50Hz)
COMP2:+9dB(50Hz)
COMP of 3:+10dB (50Hz), +6dB (20kHz)
(with Volume control and -30dB)
Disc height rimming DISC1, DISC2, 0dB - -8dB continuation variable (with 20kHz)
Attenuator - A 10dB -20dB-30dB change type
Subsonic Filter 17Hz, 12 dB/oct
The semiconductor used 159Tr, 10FET, 102Di
Power source 100V, 117V, 220V, 240V, 50/60Hz
Power consumption 80W
Dimensions Width 466x height 188x depth of 391mm
Weight 18kg
