Accuphase金嗓子 金嗓子Accuphase C-245

上市参考售价:¥16,000

推出年代:2001.12

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%

器材规格

Form Stereo control amplifier
Frequency response Balanced, Unbalanced input :
3Hz-300Hz+0 -3.0 dB
20Hz-20kHz+0 -0.2 dB
THD 0.005%
Input sensitivity/impedance
(An Output power / 0.5V output) Balanced: 252mV/63mV/40kohm
Unbalanced: 252mV/63mV/10kohm
An Output power/impedance Balanced, Unbalanced output:2V/50 ohm
Tape rec: 252mV/200 ohms
S/N, input conversion noise
Input short-circuit and A-compensation EIA S/N Remains noise
At the time of an Output power S/N Input conversion noise
Balanced: 108dB -120dBV 97dB 1.0 microvolts
Unbalanced: 121dB -133dBV 97dB 1.0 microvolts
Maximum-except-take-off level
(Distortion 0.005%, 20Hz - 20kHz) Balanced, Unbalanced output:5.0V
Tape rec:5.0V
Minimum load impedance Balanced, Unbalanced output: 600ohms
Tape rec: 10kohm
Gain Balanced, Unbalanced input -> Balanced, Unbalanced output: 18dB
Balanced, Unbalanced input -> Rec output: 0dB
Tone control Low-pitched sound (300Hz): ±10dB (50Hz)
Loud sound (3kHz): ±10dB (20kHz)
Loudness Compensation + 6dB (100Hz, Volume-30dB)
Attenuator -20dB
Headphone jack Conformity impedance: 8ohms - 100ohms
Power source AC100V, 50Hz/60Hz
Power consumption 16W
The maximum Dimensions Width 475x height 150x depth of 409mm
Weight 16.8kg
Attachment: Remote commander RC-20
Remote control system Infrared pulse system
Power source DC 3V
Battery AA -- type and two pieces
The maximum Dimensions Width 55x height 194x depth of 18mm
Weight 100g (Battery included)
Option: Option board
