器材规格
2 way, true linear phase, free space, ported enclosure, stand mounted monitor
Drive units: 1 x 170mm Wilson Benesch Tactic bass / mid range unit, 1 x 25mm Soft dome, hand painted silk, ultra linear Wilson Benesch specification tweeter
Low frequency loading: Double reflex port tuning
Frequency range: -6dB at 42Hz and 30kHz, -3dB at 45Hz and 25kHz
Frequency response: 46Hz to 24kHz +- 2dB on axis
Sensitivity: 88dB spl at 1metre on axis. 2.83V input
Impedance: 6 Ω nominal, 4 Ω minimum
Crossover: First order mid range crossover, Second order tweeter crossover, Selected polypropylene capacitors and air cored inductors are used throughout
Crossover frequencies: 5kHz
Internal wiring: Multi stranded, silver plated copper, PTFE jacketed cable harnesses, Soldered connections throughout Shortpath P.C.B. design, Links supplied for single or bi-wire applications
Input connections: Bi-wireable, in-house machined gold plated copper alloy terminals
Power handling: 200W Maximum spl: 111dB at 1 metre
Dimensions (HxWxD): 310mm (on stand 950mm) x 230mm x 370mm
Internal volume: 10.5 litres
Net weight: 11kg
Drive units: 1 x 170mm Wilson Benesch Tactic bass / mid range unit, 1 x 25mm Soft dome, hand painted silk, ultra linear Wilson Benesch specification tweeter
Low frequency loading: Double reflex port tuning
Frequency range: -6dB at 42Hz and 30kHz, -3dB at 45Hz and 25kHz
Frequency response: 46Hz to 24kHz +- 2dB on axis
Sensitivity: 88dB spl at 1metre on axis. 2.83V input
Impedance: 6 Ω nominal, 4 Ω minimum
Crossover: First order mid range crossover, Second order tweeter crossover, Selected polypropylene capacitors and air cored inductors are used throughout
Crossover frequencies: 5kHz
Internal wiring: Multi stranded, silver plated copper, PTFE jacketed cable harnesses, Soldered connections throughout Shortpath P.C.B. design, Links supplied for single or bi-wire applications
Input connections: Bi-wireable, in-house machined gold plated copper alloy terminals
Power handling: 200W Maximum spl: 111dB at 1 metre
Dimensions (HxWxD): 310mm (on stand 950mm) x 230mm x 370mm
Internal volume: 10.5 litres
Net weight: 11kg
