Accuphase金嗓子 金嗓子Accuphase A-100

上市参考售价:¥47,500

推出年代:1991.11

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%
one set

器材规格

Form Monophonic power amplifier
Continuation average output
(For 20Hz - 20kHz) 2ohm load: 400W
4ohm load: 200W
8ohm load: 100W
16ohm load: 50W
THD
(Between 0.25W - a continuation average output) 2ohm load: 0.02%
4-16ohm load: 0.01%
IM distortion 0.003%
Frequency response 20Hz - 20000Hz, ±0dB (at the time of a continuation average output level-control MAX)
0.5Hz - 150000Hz, and +0 -3.0 dB (at the time of 1W output level-control MAX)
0.5Hz - 80000Hz, and +0 -3.0 dB (at the time of 1W output level-control -6dB)
Gain (profit) 28dB
Load impedance 2-16ohm
Dumping factor 250 (8-ohm load, 50Hz)
Input sensitivity (8-ohm load) At the time of a continuation average output: 1.13V
At the time of 1W output: 0.12V
Input impedance Unbalance: 20kohm
Balance: 40kohm
S/N (A-compensation) 120dB (at the time of input short-circuit and a continuation average output)
Power meter Logarithm compression peak level display
dB scale and the output Direct reading at the time of 8-ohm load
The semiconductor used 16Tr, 44FET, 10IC, 44Di
Power source 100V, 117V, 220V, 240V, 50Hz/60Hz
Power consumption At the time of no inputting: 350W
Electrical Appliance and Material Control Law: 480W
At the time of an 8ohm load Output power: 350W
Dimensions the width 475x height 240(piece -- it includeds) x depth of 553mm (handle 含む)
Weight 57.0kg
