器材规格
Form Stereo power amplifier
Continuation average output (20Hz - 20kHz)
At the time of stereo specification (both ch(es) operation) : 170 W/ch (4ohms)
120 W/ch (8ohms)
60 W/ch (16ohms)
At the time of monophonic specification (bridge connection) : 340W (8ohms)
240W (16ohms)
THD
At the time of stereo specification (both ch(es) operation) : 0.02% (4ohms)
0.01% (8ohm-16ohm)
At the time of monophonic specification (bridge connection) : 0.02% (8ohm-16ohm)
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a continuation average output level-control maximum)
0.5Hz-160kHz+0 -3.0 dB (at the time of 1W output the level-control maximum --6dB)
Gain (profit) 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 4ohms - 16ohms
At the time of monophonic specification (bridge connection): 8ohms - 16ohms
Dumping factor At the time of stereo specification: 200
At the time of monophonic specification (bridge connection): 100
Input sensitivity (8ohms)
At the time of stereo specification
(both chanenl operation) : 1.23V (at the time of a continuation average output)
0.12V (at the time of 1W output)
At the time of monophonic specification
(bridge connection) : 2.08V (at the time of a continuation average output)
0.12V (at the time of 1W output)
Input impedance Balance: 40kohm
Unbalance: 20kohm
S/N (A compensation) 115dB (at the time of input short-circuit and a continuation average output)
93dB (at the time of input 1kohm and 1W output)
Stereo head phone Conformity impedance: 4ohms - 100ohms
The semiconductor used Transistor: 41 pieces
FET: 14 pieces
IC: Four pieces
Diode: 60 pieces
Power supply voltage AC100V/117V/220V/240V, 50Hz/60Hz
Power consumption At the time of no inputting: 45W
Electrical Appliance and Material Control Law: 300W
At the time of an 8ohm Output power: 480W
Dimensions the width 445x height 131(piece -- it includeds) x depth of 388mm
Weight 18.1kg
Continuation average output (20Hz - 20kHz)
At the time of stereo specification (both ch(es) operation) : 170 W/ch (4ohms)
120 W/ch (8ohms)
60 W/ch (16ohms)
At the time of monophonic specification (bridge connection) : 340W (8ohms)
240W (16ohms)
THD
At the time of stereo specification (both ch(es) operation) : 0.02% (4ohms)
0.01% (8ohm-16ohm)
At the time of monophonic specification (bridge connection) : 0.02% (8ohm-16ohm)
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a continuation average output level-control maximum)
0.5Hz-160kHz+0 -3.0 dB (at the time of 1W output the level-control maximum --6dB)
Gain (profit) 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 4ohms - 16ohms
At the time of monophonic specification (bridge connection): 8ohms - 16ohms
Dumping factor At the time of stereo specification: 200
At the time of monophonic specification (bridge connection): 100
Input sensitivity (8ohms)
At the time of stereo specification
(both chanenl operation) : 1.23V (at the time of a continuation average output)
0.12V (at the time of 1W output)
At the time of monophonic specification
(bridge connection) : 2.08V (at the time of a continuation average output)
0.12V (at the time of 1W output)
Input impedance Balance: 40kohm
Unbalance: 20kohm
S/N (A compensation) 115dB (at the time of input short-circuit and a continuation average output)
93dB (at the time of input 1kohm and 1W output)
Stereo head phone Conformity impedance: 4ohms - 100ohms
The semiconductor used Transistor: 41 pieces
FET: 14 pieces
IC: Four pieces
Diode: 60 pieces
Power supply voltage AC100V/117V/220V/240V, 50Hz/60Hz
Power consumption At the time of no inputting: 45W
Electrical Appliance and Material Control Law: 300W
At the time of an 8ohm Output power: 480W
Dimensions the width 445x height 131(piece -- it includeds) x depth of 388mm
Weight 18.1kg
