器材规格
Form The digital signal playback machine only for CD
Format CD standard format
The number of quantization: 16 bits
Sampling frequency: 44.1kHz
Error correcting system: CIRC
The number of channels: Two channels
Number of rotations: 500-200rpm (CLV)
Performance speed: 1.2 - 1.4 m/s regularity
Reading system Non-contact optical reading (semiconductor laser use)
Laser GaAlAs (it is a terrorism diode to double)
Frequency response 4.0Hz-20000Hz±0.3dB
D/A converter Rudder resistance type 18 bit
Digital filter 8 time oversampling
Noise shaver function
Digital demphasis function
Deflection of ±0.001dB
THD + noise 0.002% (for 20Hz - 20000Hz)
S/N 114dB
Dynamic range 98dB
Channel separation 106dB
An Output power/Output load impedance Balanced: 2.5V/50 ohm (25ohm/25ohm), a balanced XLR type
Unbalanced: 2.5V/50 ohm, a RCA phono jack
Digital level control: For 0 - -24dB, a 1dB step
Digital output format level Format: Digital Audio Interface
Optical:optical power: -21 - -15dBm (EIAJ), and luminescence wavelength:660nm
Coaxial: 0.5 Vp-p/75ohms
The semiconductor used Transistor: 15 pieces
IC: 46 pieces
Diode: 26 pieces
Power source AC100V/117V/220V/240V, 50Hz/60Hz
Power consumption 20W
Dimensions the width 445x height 95(piece -- it includeds) x depth of 325mm
Weight 13.7kg
Attachment: Remote commander RC-4
Remote control system Infrared pulse system
Power source DC 3V
Battery SUM-3 (an IEC name, R6), two pieces
The maximum Dimensions Width 64x height 176x depth of 18mm
Weight 180g (Battery included)
Format CD standard format
The number of quantization: 16 bits
Sampling frequency: 44.1kHz
Error correcting system: CIRC
The number of channels: Two channels
Number of rotations: 500-200rpm (CLV)
Performance speed: 1.2 - 1.4 m/s regularity
Reading system Non-contact optical reading (semiconductor laser use)
Laser GaAlAs (it is a terrorism diode to double)
Frequency response 4.0Hz-20000Hz±0.3dB
D/A converter Rudder resistance type 18 bit
Digital filter 8 time oversampling
Noise shaver function
Digital demphasis function
Deflection of ±0.001dB
THD + noise 0.002% (for 20Hz - 20000Hz)
S/N 114dB
Dynamic range 98dB
Channel separation 106dB
An Output power/Output load impedance Balanced: 2.5V/50 ohm (25ohm/25ohm), a balanced XLR type
Unbalanced: 2.5V/50 ohm, a RCA phono jack
Digital level control: For 0 - -24dB, a 1dB step
Digital output format level Format: Digital Audio Interface
Optical:optical power: -21 - -15dBm (EIAJ), and luminescence wavelength:660nm
Coaxial: 0.5 Vp-p/75ohms
The semiconductor used Transistor: 15 pieces
IC: 46 pieces
Diode: 26 pieces
Power source AC100V/117V/220V/240V, 50Hz/60Hz
Power consumption 20W
Dimensions the width 445x height 95(piece -- it includeds) x depth of 325mm
Weight 13.7kg
Attachment: Remote commander RC-4
Remote control system Infrared pulse system
Power source DC 3V
Battery SUM-3 (an IEC name, R6), two pieces
The maximum Dimensions Width 64x height 176x depth of 18mm
Weight 180g (Battery included)
