器材规格
Form Stereo power amplifier
Continuation average output
(20Hz - 20kHz)
At the time of stereo specification : 210 W/ch (4ohms)
180 W/ch (6ohms)
150 W/ch (8ohms)
At the time of monophonic specification :
(Bridge connection) 420W (8ohms)
300W (16ohms)
THD At the time of stereo specification: 0.02% (4ohms - 16-ohm load)
At the time of monophonic specification: 0.02% (8ohms - 16-ohm load)
IM distortion 0.02%
Frequency response 20Hz-20kHz+0 -0.2dB (at the time of a continuation average output)
0.5Hz-160kHz+0 -3.0dB (at the time of 1W output)
Gain 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 4ohms - 16ohms
At the time of monophonic specification (bridge connection): 8ohms - 16ohms
Dumping factor At the time of stereo specification: 360
At the time of monophonic specification (bridge connection): 180
Input sensitivity
(at the time of 8-ohm load)
At the time of stereo specification : 1.38V (at the time of a continuation average output)
0.11V (at the time of 1W output)
At the time of monophonic specification :
(Bridge connection) 2.31V (at the time of a continuation average output)
0.11V (at the time of 1W output)
Input impedance Imbalanced Input: 20kohm
Balance input: 40kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a continuation average output)
Power source AC100V, 50Hz/60Hz
Power consumption 65W (at the time of no inputting)
300W (Electrical Appliance and Material Control Law)
490W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 170x depth of 435mm
Weight 23.6kg
Continuation average output
(20Hz - 20kHz)
At the time of stereo specification : 210 W/ch (4ohms)
180 W/ch (6ohms)
150 W/ch (8ohms)
At the time of monophonic specification :
(Bridge connection) 420W (8ohms)
300W (16ohms)
THD At the time of stereo specification: 0.02% (4ohms - 16-ohm load)
At the time of monophonic specification: 0.02% (8ohms - 16-ohm load)
IM distortion 0.02%
Frequency response 20Hz-20kHz+0 -0.2dB (at the time of a continuation average output)
0.5Hz-160kHz+0 -3.0dB (at the time of 1W output)
Gain 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 4ohms - 16ohms
At the time of monophonic specification (bridge connection): 8ohms - 16ohms
Dumping factor At the time of stereo specification: 360
At the time of monophonic specification (bridge connection): 180
Input sensitivity
(at the time of 8-ohm load)
At the time of stereo specification : 1.38V (at the time of a continuation average output)
0.11V (at the time of 1W output)
At the time of monophonic specification :
(Bridge connection) 2.31V (at the time of a continuation average output)
0.11V (at the time of 1W output)
Input impedance Imbalanced Input: 20kohm
Balance input: 40kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a continuation average output)
Power source AC100V, 50Hz/60Hz
Power consumption 65W (at the time of no inputting)
300W (Electrical Appliance and Material Control Law)
490W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 170x depth of 435mm
Weight 23.6kg
