器材规格
Form Stereo power amplifier
Continuation average output
(20Hz - 20kHz)
At the time of stereo specification : 650 W/ch (it restricts to 1 ohm and a music signal)
400 W/ch (2ohms)
200 W/ch (4ohms)
100 W/ch (8ohms)
At the time of monophonic specification :
(Bridge connection) 1300W (it restricts to 2 ohms and a music signal)
800W (4ohms)
400W (8ohms)
THD
At the time of stereo specification : 0.05% (2ohms)
0.02% (4ohm-16ohm)
At the time of monophonic specification : 0.02% (4ohm-16ohm)
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a rated continuation average output)
0.5Hz-160kHz+0 -3.0dB (at the time of 1W output)
Gain 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 2ohms - 16ohms
At the time of monophonic specification: 4ohms - 16ohms
* Restrict to a music signal and Stereo 1 ohm and monophonic 2ohm load are possible.
Dumping factor 270 (at the time of a stereo / monophonic specification)
Input sensitivity (8-ohm load)
At the time of stereo specification : 1.12V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
At the time of monophonic specification : 2.25V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
Input impedance Imbalanced Input: 20kohm
Balance input: 40kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a rated continuation average output)
Power output meter A logarithm compression type, with a display putting-out-lights function
- 50dB - +3dB
Power source AC100V, 50Hz/60Hz
Power consumption 80W (at the time of no inputting)
625W (Electrical Appliance and Material Control Law)
390W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 223x depth of 491mm
Weight 38kg
Continuation average output
(20Hz - 20kHz)
At the time of stereo specification : 650 W/ch (it restricts to 1 ohm and a music signal)
400 W/ch (2ohms)
200 W/ch (4ohms)
100 W/ch (8ohms)
At the time of monophonic specification :
(Bridge connection) 1300W (it restricts to 2 ohms and a music signal)
800W (4ohms)
400W (8ohms)
THD
At the time of stereo specification : 0.05% (2ohms)
0.02% (4ohm-16ohm)
At the time of monophonic specification : 0.02% (4ohm-16ohm)
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a rated continuation average output)
0.5Hz-160kHz+0 -3.0dB (at the time of 1W output)
Gain 28.0dB (at the time of a stereo / monophonic specification)
Load impedance At the time of stereo specification: 2ohms - 16ohms
At the time of monophonic specification: 4ohms - 16ohms
* Restrict to a music signal and Stereo 1 ohm and monophonic 2ohm load are possible.
Dumping factor 270 (at the time of a stereo / monophonic specification)
Input sensitivity (8-ohm load)
At the time of stereo specification : 1.12V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
At the time of monophonic specification : 2.25V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
Input impedance Imbalanced Input: 20kohm
Balance input: 40kohm
S/N (A compensation) 120dB (at the time of input short-circuit and a rated continuation average output)
Power output meter A logarithm compression type, with a display putting-out-lights function
- 50dB - +3dB
Power source AC100V, 50Hz/60Hz
Power consumption 80W (at the time of no inputting)
625W (Electrical Appliance and Material Control Law)
390W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 223x depth of 491mm
Weight 38kg
