Accuphase金嗓子 金嗓子Accuphase P-1000

上市参考售价:¥55,000

推出年代:1999.6

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%

器材规格

Form Stereo power amplifier
Rated continuation average output
(20Hz - 20kHz)
At the time of stereo specification
(both channel operation) : 1,000 W/ch (it restricts to 1 ohm and a music signal)
500 W/ch (2ohms)
250 W/ch (4ohms)
125 W/ch (8ohms)
At the time of mono specification
(bridge connection) : 2,000W (it restricts to 2 ohms and a music signal)
1,000W (4ohms)
500W (8ohms)
THD
At the time of stereo specification (both ch(es) operation) : 0.05% (2ohms)
0.03% (4ohm-16ohm)
At the time of mono specification (bridge connection) : 0.03% (4ohm-16ohm)
IM distortion 0.003%
Frequency response 20Hz-20kHz+0 -0.2 dB (at the time of a rated continuation average output)
0.5Hz-150kHz+0 -3.0dB (at the time of 1W output)
Gain (profit) 28.0dB (at the time of stereo/mono specification)
Load impedance At the time of stereo specification: 2ohms - 16ohms
At the time of mono specification: 4ohms - 16ohms
* Restrict to a music signal and stereo1ohm and mono2ohm load are possible.
Dumping factor 300 (at the time of stereo/mono specification)
Input sensitivity (8-ohm load)
At the time of stereo specification : 1.26V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
At the time of mono specification : 2.52V (at the time of a rated continuation average output)
0.11V (at the time of 1W output)
Input impedance Balance input: 40kohm
Imbalanced Input: 20kohm
S/N
(A compensation, input short-circuit) 114dB (at the time of a rated continuation average output)
117dB (at the time of a clipping output)
Power output meter A logarithm compression type, with a display putting-out-lights function
- 60dB - +3dB, and the output Direct-reading scale of 2-ohm load
Power source AC100V, 50Hz/60Hz
Power consumption 148W (at the time of no inputting)
1,070W (Electrical Appliance and Material Control Law)
635W (at the time of an 8-ohm load Output power)
The maximum Dimensions Width 475x height 258x depth of 545mm
Weight 50kg
