器材规格
Form Monophonic preamplifier
Stream composition Perfect monophonic stream composition
It is a plug-in per piece each to each ch phone amplifier and line amplifier.
Gain Phone amplifier: 38dB, 44dB (switching)
At the time of L3 plug-in using: 66dB
At the time of an L3A plug-in using: 54dB
Line amplifier: 10dB, 20dB, 26dB (switching)
Input impedance Phone amplifier: 50kohm, 820ohms (switching)
At the time of L3 plug-in using: 825ohms
At the time of an L3A plug-in using: 825ohm
Line amplifier: 10kohm
Output load impedance Phone amplifier (Tape out): 1.2kohm
Lineout (Main out): 47ohms
Power source AC100V, 50Hz/60Hz
Power consumption 35W
Dimensions Main unit: Width 483x height 51x depth of 156mm
Power-source part: Width 101x height 101x depth of 269mm
Weight Main unit: 2.5kg
Power-source part: 2.4kg
Stream composition Perfect monophonic stream composition
It is a plug-in per piece each to each ch phone amplifier and line amplifier.
Gain Phone amplifier: 38dB, 44dB (switching)
At the time of L3 plug-in using: 66dB
At the time of an L3A plug-in using: 54dB
Line amplifier: 10dB, 20dB, 26dB (switching)
Input impedance Phone amplifier: 50kohm, 820ohms (switching)
At the time of L3 plug-in using: 825ohms
At the time of an L3A plug-in using: 825ohm
Line amplifier: 10kohm
Output load impedance Phone amplifier (Tape out): 1.2kohm
Lineout (Main out): 47ohms
Power source AC100V, 50Hz/60Hz
Power consumption 35W
Dimensions Main unit: Width 483x height 51x depth of 156mm
Power-source part: Width 101x height 101x depth of 269mm
Weight Main unit: 2.5kg
Power-source part: 2.4kg
