1988年——¥49000
1990年——¥46000
1990年——¥46000
器材规格
Form Preamplifier
Stream composition The stereo preamplifier by a dual monophonic stream composition
Gain Phone amplifier man month: 38dB, 44dB
Phone amplifier MC: 58dB, 64dB
Unbalance: 6dB, 12dB, 18dB
Balance: 12dB, 18dB, 24dB
Input impedance Phone amplifier man-month:47kohm (a switchover variable is possible)
Phone amplifier MC: 825ohms (a switchover variable is possible)
Line amplifier: 14kohm
Maximum output Phone amplifier: 6V (Tape out)
Line amplifier: 6V (Main out)
Power source AC100V, 50Hz/60Hz
Power consumption 50W
Dimensions Main unit: Width 444.5x height 78.5x depth of 333.4mm
Power-source part: Width 193.0x height 78.5x depth of 333.4mm
Weight Main unit: 4.5kg
Power-source part: 3.6kg
Stream composition The stereo preamplifier by a dual monophonic stream composition
Gain Phone amplifier man month: 38dB, 44dB
Phone amplifier MC: 58dB, 64dB
Unbalance: 6dB, 12dB, 18dB
Balance: 12dB, 18dB, 24dB
Input impedance Phone amplifier man-month:47kohm (a switchover variable is possible)
Phone amplifier MC: 825ohms (a switchover variable is possible)
Line amplifier: 14kohm
Maximum output Phone amplifier: 6V (Tape out)
Line amplifier: 6V (Main out)
Power source AC100V, 50Hz/60Hz
Power consumption 50W
Dimensions Main unit: Width 444.5x height 78.5x depth of 333.4mm
Power-source part: Width 193.0x height 78.5x depth of 333.4mm
Weight Main unit: 4.5kg
Power-source part: 3.6kg
