(May, 1991 release) ¥80000
(balance input card equipment) ¥90000
(man-month phone card equipment) ¥92500
(MC phone card equipment) ¥92500
(balance input card equipment) ¥90000
(man-month phone card equipment) ¥92500
(MC phone card equipment) ¥92500
器材规格
Form Control amplifier
Stream composition Dual monophonic stream composition
Gain Phone amplifier man month: 38dB, 44dB
Phone amplifier MC: 58dB, 64dB
Line amplifier Unbalanced: 6dB, 12dB, 18dB
Line amplifier Balanced: 12dB, 18dB, 24dB
Input impedance man-month: 47kohm (a modification is possible)
MC: 825ohms (a modification is possible)
Line amplifier: 14kohm
Maximum output Phone amplifier: 6V (Tape out)
Line amplifier: 6V (Main out)
Special function Absolute phase control switchpoint
Tapes output defeet switchpoint
Power source AC100V, 50Hz/60Hz
Power consumption 50W
Dimensions Main unit: Width 444.5x height 78x depth of 333mm
Power source: Width 193x height 78x depth of 333mm
Weight Main unit: 4.5kg
Power source: 3.6kg
Stream composition Dual monophonic stream composition
Gain Phone amplifier man month: 38dB, 44dB
Phone amplifier MC: 58dB, 64dB
Line amplifier Unbalanced: 6dB, 12dB, 18dB
Line amplifier Balanced: 12dB, 18dB, 24dB
Input impedance man-month: 47kohm (a modification is possible)
MC: 825ohms (a modification is possible)
Line amplifier: 14kohm
Maximum output Phone amplifier: 6V (Tape out)
Line amplifier: 6V (Main out)
Special function Absolute phase control switchpoint
Tapes output defeet switchpoint
Power source AC100V, 50Hz/60Hz
Power consumption 50W
Dimensions Main unit: Width 444.5x height 78x depth of 333mm
Power source: Width 193x height 78x depth of 333mm
Weight Main unit: 4.5kg
Power source: 3.6kg
