器材规格
Form Digital analog converter
Digital input XLR: Five lines
EIAJ optical: two lines
ST optical: one line
Analog output XLR: Four lines
RCA: Two lines
Digital output XLR: Two lines (a monitor/Rec)
EIAJ optical: one line (Rec)
Digital analog converter Precision dual 20-bit DACx2
Filtering 8 time oversampling digital filter
Bessel syntony linear phase analog filter
Frequency characteristic 10Hz-20kHz+0dB-0.2dB
THD 0.003% or less (1kHz, 0dB, A correction)
Dynamic range 98dB or more
SN ratio 105dB
Channel separation 110dB or more
IM distortion (SMPTE, IMD) 0.005% or less
Low level linearity - It is below a limit of measurement to 70dB or less.
- It is about +1.7dB (dither nothing, 0dB, 1kHz) to 90dB or less.
Output load impedance 6ohms or less
Dimensions Main unit: Width 492x height 187x depth of 392mm
Power source: Width 400x height 133x depth of 378mm
Weight Main unit: 15.8kg
Power source: 12.8kg
Digital input XLR: Five lines
EIAJ optical: two lines
ST optical: one line
Analog output XLR: Four lines
RCA: Two lines
Digital output XLR: Two lines (a monitor/Rec)
EIAJ optical: one line (Rec)
Digital analog converter Precision dual 20-bit DACx2
Filtering 8 time oversampling digital filter
Bessel syntony linear phase analog filter
Frequency characteristic 10Hz-20kHz+0dB-0.2dB
THD 0.003% or less (1kHz, 0dB, A correction)
Dynamic range 98dB or more
SN ratio 105dB
Channel separation 110dB or more
IM distortion (SMPTE, IMD) 0.005% or less
Low level linearity - It is below a limit of measurement to 70dB or less.
- It is about +1.7dB (dither nothing, 0dB, 1kHz) to 90dB or less.
Output load impedance 6ohms or less
Dimensions Main unit: Width 492x height 187x depth of 392mm
Power source: Width 400x height 133x depth of 378mm
Weight Main unit: 15.8kg
Power source: 12.8kg
