器材规格
Line Inputs 5 plus Tape
Input Impedance 47 kΩ
Input Sensitivity (70W) Line 240mV
Line Outputs Tape, Preamplifier (x2)
Output Voltage 240mV (Tape Out)
700mV (Pre Out)
Power Outputs Loudspeaker, L & R
Output Power >85 Watts, into 8Ω
both channels driven
>120 Watts, into 4Ω
both channels driven
Power Supply 350VA Ultra Low Noise Toroidal Transformer
4 Regulated Supply Rails
Current Output 50 Amps Peak to Peak
Damping Factor >140 (8Ω)
Frequency Response -3dB, <1Hz – 90kHz
Gain 40dB Overall (Pre & Power)
9.3dB Preamplifier
30.7dB Power Amplifier
Harmonic Distortion 0.002% 1kHz, 0.015% 20kHz 10W - 8Ω
0.0025% 1kHz, 0.03% 20kHz 50W - 8Ω
Signal to Noise Ratio Line 108dBa (ref. 500mV)
85dBa (ref. 1W, 8Ω)
Power Source 100V – 120V 50Hz / 60Hz
220V – 240V 50Hz / 60Hz
(via Mains inlet filter)
Power Consumption < 230 W
Dimension 432 x 330 x 70 (W x D x H) mm
432 x 330 x 80 (including feet)
Weight 12 Kg
Input Impedance 47 kΩ
Input Sensitivity (70W) Line 240mV
Line Outputs Tape, Preamplifier (x2)
Output Voltage 240mV (Tape Out)
700mV (Pre Out)
Power Outputs Loudspeaker, L & R
Output Power >85 Watts, into 8Ω
both channels driven
>120 Watts, into 4Ω
both channels driven
Power Supply 350VA Ultra Low Noise Toroidal Transformer
4 Regulated Supply Rails
Current Output 50 Amps Peak to Peak
Damping Factor >140 (8Ω)
Frequency Response -3dB, <1Hz – 90kHz
Gain 40dB Overall (Pre & Power)
9.3dB Preamplifier
30.7dB Power Amplifier
Harmonic Distortion 0.002% 1kHz, 0.015% 20kHz 10W - 8Ω
0.0025% 1kHz, 0.03% 20kHz 50W - 8Ω
Signal to Noise Ratio Line 108dBa (ref. 500mV)
85dBa (ref. 1W, 8Ω)
Power Source 100V – 120V 50Hz / 60Hz
220V – 240V 50Hz / 60Hz
(via Mains inlet filter)
Power Consumption < 230 W
Dimension 432 x 330 x 70 (W x D x H) mm
432 x 330 x 80 (including feet)
Weight 12 Kg
