器材规格
Form Stereo preamplifier
An input terminal/impedance Phono man month: 47kohm
Phono MC: 5ohm-1kohm (nine-step switching)
compact-disk: 47kohm
Tuner, AUX, Tape1, 2:10kohm
An output-terminal/impedance Pre Out1, 2, Tape Out: 10ohms
THD Phono: 0.01% or less
Tuner: 0.002% or less
Frequency characteristic 20Hz - -20kHz 0.005dB (AUX-Pre Out)
SN ratio (IHF-A) Phono:95dB
AUX:100dB
Phono maximum permissible input (1kHz) MM:200mV
MC:10mV
Supply voltage AC100V, 50Hz/60Hz
Power consumption 15W
Dimensions Main unit: Width 483x height 67x depth of 342mm (connector)
Power-source part: Width 75x height 80x depth of 228mm
Weight Main unit: About 4.4kg
Power-source part: About 1.6kg
An input terminal/impedance Phono man month: 47kohm
Phono MC: 5ohm-1kohm (nine-step switching)
compact-disk: 47kohm
Tuner, AUX, Tape1, 2:10kohm
An output-terminal/impedance Pre Out1, 2, Tape Out: 10ohms
THD Phono: 0.01% or less
Tuner: 0.002% or less
Frequency characteristic 20Hz - -20kHz 0.005dB (AUX-Pre Out)
SN ratio (IHF-A) Phono:95dB
AUX:100dB
Phono maximum permissible input (1kHz) MM:200mV
MC:10mV
Supply voltage AC100V, 50Hz/60Hz
Power consumption 15W
Dimensions Main unit: Width 483x height 67x depth of 342mm (connector)
Power-source part: Width 75x height 80x depth of 228mm
Weight Main unit: About 4.4kg
Power-source part: About 1.6kg
