器材规格
Form Control amplifier
Output power (20Hz - 20kHz) Balanced:1.7V
Unbalanced:1.7V
Maximum output (20Hz - 20kHz) Balanced:13.5V
Unbalanced:13.5V
THD (20Hz - 20kHz) Balanced:0.0015%
Unbalanced:0.003%
Frequency characteristic Balanced: 3Hz-150kHz+0 -3dB
Unbalanced: 3Hz-150kHz+0 -3dB
Input sensitivity/impedance Balanced: 420mV / 20kohm
Unbalanced: 420mV / 20kohm
Output load impedance Balanced: 220ohms
Unbalanced: 220ohms
S/N (IHF-A network) Balanced:103dB
Unbalanced:105dB
Channel separation (20kHz) Balanced: 100dB or more
Unbalanced: 100dB or more
Volume span of adjustable range - infinity, -100dB-0dB (0.5dB step)
Trim level span of adjustable range ±6dB (0.5dB step)
ATT set point - 20, -40, -60, -infinitydecibel
Input/output terminal Balance input: One line
Imbalanced input: Three lines (SACD/compact disk, Line1, 2)
Tape in/out: 1 line
Balance output: One line
Imbalanced output: Two lines
Supply voltage AC100V, 50Hz/60Hz
Power consumption 18W
The maximum Dimensions Width 459x height 136x depth of 441mm
Weight 21kg
Adjunct AC cable
Remote cable
Remote controller (rc-7S1SC)
Output power (20Hz - 20kHz) Balanced:1.7V
Unbalanced:1.7V
Maximum output (20Hz - 20kHz) Balanced:13.5V
Unbalanced:13.5V
THD (20Hz - 20kHz) Balanced:0.0015%
Unbalanced:0.003%
Frequency characteristic Balanced: 3Hz-150kHz+0 -3dB
Unbalanced: 3Hz-150kHz+0 -3dB
Input sensitivity/impedance Balanced: 420mV / 20kohm
Unbalanced: 420mV / 20kohm
Output load impedance Balanced: 220ohms
Unbalanced: 220ohms
S/N (IHF-A network) Balanced:103dB
Unbalanced:105dB
Channel separation (20kHz) Balanced: 100dB or more
Unbalanced: 100dB or more
Volume span of adjustable range - infinity, -100dB-0dB (0.5dB step)
Trim level span of adjustable range ±6dB (0.5dB step)
ATT set point - 20, -40, -60, -infinitydecibel
Input/output terminal Balance input: One line
Imbalanced input: Three lines (SACD/compact disk, Line1, 2)
Tape in/out: 1 line
Balance output: One line
Imbalanced output: Two lines
Supply voltage AC100V, 50Hz/60Hz
Power consumption 18W
The maximum Dimensions Width 459x height 136x depth of 441mm
Weight 21kg
Adjunct AC cable
Remote cable
Remote controller (rc-7S1SC)
