MARANTZ 马兰士Marantz AX1000

上市参考售价:¥95,000

推出年代:1994

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%
       AX1000音频处理器是一款全数字的信号处理器,应用了最先进的1比特模拟数字转换器和SAA7350比特流数字模拟转换器。通过一个三频带参量均衡器、一个能够模拟已知表演大厅的反响特点的声场处理器、一个压缩器或限制器、一个降噪器、一个方波/白噪声/粉红噪声发生器和实时分析器,AX1000能够在试听室中测量并补偿音频缺陷。

器材规格

Form Audio computer
Input terminal Digital coaxial input: One line
Digital light input: Two lines
Analog imbalanced input: One line
Analog balance input: One line
The mike input for a measurement: One line
Output-terminal
Front output : Digital coaxial output: One line
Digital optical power: Two lines
Analog imbalanced output: One line
Analog balance output: One line
Rear output : Digital coaxial output: One line
Digital optical power: One line
Analog imbalanced output: One line
Center output : Analog imbalanced output: One line
Display-device output : TTL-RGB output: One line
S-terminal output: One line
An analog input sensitivity / impedance 500mV / 10kohm
Analog output level / impedance 2V/50 ohm

THD (0dB, 1kHz) 0.003%
Frequency characteristic (44.1kHz) 15Hz - 20kHz
SN ratio 90dB

THD (0dB, 1kHz) 0.003%
Frequency characteristic (44.1kHz) 15Hz - 20kHz
SN ratio 100dB
Channel separation 100dB(1kHz)
Digital input sensitivity Coaxial: 0.5 Vp-p
Light: -19dBm--21dBm
Digital output level Coaxial: 0.5 Vp-p

Frequency characteristic 20Hz - 20kHz

Supply voltage AC100V, 50Hz/60Hz
Power consumption 50W
The maximum Dimensions Width 482x height 166x depth of 418mm
Weight 15.5kg
Adjunct Remote control
The mic for a measurement
