mcintosh麦景图 麦景图McIntosh C42

上市参考售价:¥32,500

推出年代:1995

0.00

  • (0人评价)
  • 0%
  • 0%
  • 0%
  • 0%
  • 0%

器材规格

Form Audio control center
Frequency characteristic 20Hz-20kHz+0 -0.5 dB
THD 0.002% or less (at the time of an Output power 20Hz - 20kHz)
SN ratio (A-Weighted) Phono:86dB
High Level:97dB
Output power 2.5Vrms (Main, Output1, 2)
Maximum output voltage 10Vrms (Main, Output1, 2)
Output load impedance 240ohms
Input impedance Phono: 47kohm, 65pF
High SFT Level: 22kohm
Input sensitivity (at the time of an Output power) Phono:4.5mV
High Level:450mv
The maximum input signal Phono:50mV
High Level:5V
voltage gain (gain) Phono -> Tape out: 40dB
High SFT Level -> Tape out: 0dB
High SFT Level -> Main out: 15dB
8band special-NetWare-program equalizer 20Hz, 35Hz, 70Hz, 150Hz, 300Hz, 600Hz, 1.2kHz, 4kHz
±12dB
AC remote power source RCT translator (remote power-source terminal) adjunct
Power source AC100V, 50Hz/60Hz
Power consumption 30W
Dimensions Width 445x height 150x depth of 470mm (a knob, a termination included)
Weight 11.5kg
Adjunct Wireless remote control HR-100
