器材规格
Form Stereo preamplifier
Frequency characteristic 10Hz-40kHz+0 -0.5 dB
Output power 2.5V (a balance/unbalance a main, switched 1/2 respectively)
Output load impedance 100ohms (balance)
50ohms (unbalance)
Maximum output voltage 25.0V (the balance output of a main/switched, 10Hz - 40kHz)
12.0V (the imbalanced output of a main/switched, 10Hz - 40kHz)
THD A maximum of 0.002% (at the time of an Output power 20Hz - 20kHz)
Input sensitivity Phono: 4.4mV (at the time of 2.5V Output power 0.5mV IHF)
High SFT Level: 450mV (at the time of 2.5V Output power 50mV IHF)
S/N ratio (A network) Phono:86dB
High Level:98dB
The maximum input signal Phono MM:50mV
High SFT Level: 5V (balance)
Input impedance Phono man month: 47kohm
Phono MC: 5ohms
High SFT Level(balance): 44kohm
High SFT Level(unbalance): 22kohm
Voltage gain 70dB (MC->Tape out)
40dB (man month->Tape out)
0dB (High SFT Level->Tape out)
AC outlet Switched: Four lines
Unswitched: One line
Power source AC100V
Power consumption 25W
Dimensions Width 444x height 137x depth of 508mm (per chassis)
Weight 18.4kg (control part)
15.9kg (preamplifier part)
Adjunct Wireless remote control
Frequency characteristic 10Hz-40kHz+0 -0.5 dB
Output power 2.5V (a balance/unbalance a main, switched 1/2 respectively)
Output load impedance 100ohms (balance)
50ohms (unbalance)
Maximum output voltage 25.0V (the balance output of a main/switched, 10Hz - 40kHz)
12.0V (the imbalanced output of a main/switched, 10Hz - 40kHz)
THD A maximum of 0.002% (at the time of an Output power 20Hz - 20kHz)
Input sensitivity Phono: 4.4mV (at the time of 2.5V Output power 0.5mV IHF)
High SFT Level: 450mV (at the time of 2.5V Output power 50mV IHF)
S/N ratio (A network) Phono:86dB
High Level:98dB
The maximum input signal Phono MM:50mV
High SFT Level: 5V (balance)
Input impedance Phono man month: 47kohm
Phono MC: 5ohms
High SFT Level(balance): 44kohm
High SFT Level(unbalance): 22kohm
Voltage gain 70dB (MC->Tape out)
40dB (man month->Tape out)
0dB (High SFT Level->Tape out)
AC outlet Switched: Four lines
Unswitched: One line
Power source AC100V
Power consumption 25W
Dimensions Width 444x height 137x depth of 508mm (per chassis)
Weight 18.4kg (control part)
15.9kg (preamplifier part)
Adjunct Wireless remote control
