器材规格
Form Stereo power amplifier
Output power
(20Hz - 20kHz, sine wave) stereo: 350W+350W (2ohm, 4ohm, an 8-ohm load intensity, the succession minimum mean-value power output value)
mono parallel: 700W (1ohm, 2ohm, a 4-ohm load intensity, the succession minimum mean-value power output value)
Output-power bandwidth 20Hz - 20kHz
Output load impedance stereo: 2 ohms, 4ohm, 8ohm
mono: 1 ohm, 2ohm, 4ohm
Input sensitivity/impedance 2.2V/10kohm
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3 dB
THD 0.005% or less (250mW - an Output power, 20Hz - 20kHz, both ch(es) drive)
Cross modulation distortion
(SMPTE, both channel drive) 0.005% (instant peek power output <= Output-power x2, 20Hz - 20kHz)
SN ratio (A-Weighted) Unbalance: 85dB (116dB and below an Output power)
Balance: 115dB (124dB and below an Output power)
Sensitivity Unbalance: 1.9V
Balance: 3.8V
Input impedance Unbalance: 20kohm
Balance: 40kohm
Dumping factor 40 or more
Power guarding Prevention from clipping
THD <=2% (less than over-drive 14dB, 1kHz)
Power source AC100V, 50Hz/60 Hz, 14.4A (Underwriters Laboratories/CSA specification)
Dimensions Width 445x height 240x depth of 495mm (a knob, a terminal included)
Weight 47.63kg
Output power
(20Hz - 20kHz, sine wave) stereo: 350W+350W (2ohm, 4ohm, an 8-ohm load intensity, the succession minimum mean-value power output value)
mono parallel: 700W (1ohm, 2ohm, a 4-ohm load intensity, the succession minimum mean-value power output value)
Output-power bandwidth 20Hz - 20kHz
Output load impedance stereo: 2 ohms, 4ohm, 8ohm
mono: 1 ohm, 2ohm, 4ohm
Input sensitivity/impedance 2.2V/10kohm
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3 dB
THD 0.005% or less (250mW - an Output power, 20Hz - 20kHz, both ch(es) drive)
Cross modulation distortion
(SMPTE, both channel drive) 0.005% (instant peek power output <= Output-power x2, 20Hz - 20kHz)
SN ratio (A-Weighted) Unbalance: 85dB (116dB and below an Output power)
Balance: 115dB (124dB and below an Output power)
Sensitivity Unbalance: 1.9V
Balance: 3.8V
Input impedance Unbalance: 20kohm
Balance: 40kohm
Dumping factor 40 or more
Power guarding Prevention from clipping
THD <=2% (less than over-drive 14dB, 1kHz)
Power source AC100V, 50Hz/60 Hz, 14.4A (Underwriters Laboratories/CSA specification)
Dimensions Width 445x height 240x depth of 495mm (a knob, a terminal included)
Weight 47.63kg
