器材规格
Form Stereo power amplifier
Output power stereo: 400W+400W (2ohm, 4ohm, 8ohm)
mono parallel: 800W (1ohm, 2ohm, 4ohm)
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
THD A maximum of 0.005% (250mW - Output power)
Cross modulation distortion A maximum of 0.005% (at the time of SMPTE and an Output power)
Input sensitivity/impedance Unbalance: 1.9V / 10kohm (with VR)
Balance: 3.8V / 20kohm (with VR)
SN ratio (A-criteria) Unbalance: 85dB
Balance: 115dB
Dumping factor 100 (8ohm)
Power guarding Prevention from clipping, THD <=2% (less than over-drive 14dB, 1kHz)
Power source AC100V, 50Hz/60 Hz, 12A (Underwriters Laboratories/CSA specification)
Dimensions Width 445x height 226x depth of 445mm
Weight 47.6kg
Output power stereo: 400W+400W (2ohm, 4ohm, 8ohm)
mono parallel: 800W (1ohm, 2ohm, 4ohm)
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
THD A maximum of 0.005% (250mW - Output power)
Cross modulation distortion A maximum of 0.005% (at the time of SMPTE and an Output power)
Input sensitivity/impedance Unbalance: 1.9V / 10kohm (with VR)
Balance: 3.8V / 20kohm (with VR)
SN ratio (A-criteria) Unbalance: 85dB
Balance: 115dB
Dumping factor 100 (8ohm)
Power guarding Prevention from clipping, THD <=2% (less than over-drive 14dB, 1kHz)
Power source AC100V, 50Hz/60 Hz, 12A (Underwriters Laboratories/CSA specification)
Dimensions Width 445x height 226x depth of 445mm
Weight 47.6kg
