器材规格
Form Stereo power amplifier
Output power (sinusoidal consecutive output) stereo: 500W+500W (2ohm, 4ohm, 8ohm)
mono: 1,000W (4ohm, 8ohm, 16ohm)
Load impedance stereo: 2 ohms, 4ohm, 8ohm
mono: 4 ohms, 8ohm, 16ohm
Output frequency band 20Hz - 20kHz
THD (20Hz - 20kHz) 0.005% or less (250mW - Output power)
Cross modulation distortion (SMPTE) 0.005% (when peek power does not exceed the twice of an Output power at the moment)
Frequency band 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio (A network) 85dB
115dB (at the time of an Output power)
IHF dynamic head room 2.1dB
Dumping factor 200 (4-ohm output)
Input sensitivity/impedance 2.2V/10kohm
Power guarding Prevention from clipping. It is less than THD2% to over-drive 14dB in 1kHz.
Power source AC100V, 50Hz/60 Hz, 14.4A (Underwriters Laboratories/CSA)
Dimensions Width 445x height 255x depth of 491mm
Weight 49.9kg
Output power (sinusoidal consecutive output) stereo: 500W+500W (2ohm, 4ohm, 8ohm)
mono: 1,000W (4ohm, 8ohm, 16ohm)
Load impedance stereo: 2 ohms, 4ohm, 8ohm
mono: 4 ohms, 8ohm, 16ohm
Output frequency band 20Hz - 20kHz
THD (20Hz - 20kHz) 0.005% or less (250mW - Output power)
Cross modulation distortion (SMPTE) 0.005% (when peek power does not exceed the twice of an Output power at the moment)
Frequency band 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio (A network) 85dB
115dB (at the time of an Output power)
IHF dynamic head room 2.1dB
Dumping factor 200 (4-ohm output)
Input sensitivity/impedance 2.2V/10kohm
Power guarding Prevention from clipping. It is less than THD2% to over-drive 14dB in 1kHz.
Power source AC100V, 50Hz/60 Hz, 14.4A (Underwriters Laboratories/CSA)
Dimensions Width 445x height 255x depth of 491mm
Weight 49.9kg
