器材规格
Form Stereo power amplifier
Stereo output 100W+100W (2ohm, 4ohm, 8ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 14.2V (2ohm), 20.0V (4ohm), 28.3V (8ohm)
Mono-parallel output 200W (1ohm, 2ohm, 4ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 14.2V (1ohm), 20.0V (2ohm), 28.3V (4ohm)
Mono-bridge output 200W (4ohm, 8ohm, 16ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 28.3V (4ohm), 40.0V (8ohm), 56.6V (16ohm)
THD 0.5% or less (being all the level in 250mW - an Output power)
Intermodulation distortion (SMPTE) 0.5% or less (when peaking capacity does not exceed the twice of a rated power output at the moment)
Output-power frequency 20Hz - 20kHz
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio (A load) 100dB (below an Output power)
Wide band dumping factor 18 or more
Output load impedance Stereo: 2 ohms, 4ohm, 8ohm
Mono-parallel: 1 ohm, 2ohm, 4ohm
Mono-bridge: 4 ohms, 8ohm, 16ohm
Input impedance Unbalance: 20kohm
Balance: 40kohm
Input sensitivity 1.0V
Valves employed 12AX7x4 (an input and phase inversion)
12AT7x4 (a voltage amplification and driver)
KT88 or 6550x8 (output tube)
Power source AC100V, 50Hz/60 Hz, 5.8A
Dimensions Width 455.4x height 257.2x depth of 406.4mm
Weight 40kg
Stereo output 100W+100W (2ohm, 4ohm, 8ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 14.2V (2ohm), 20.0V (4ohm), 28.3V (8ohm)
Mono-parallel output 200W (1ohm, 2ohm, 4ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 14.2V (1ohm), 20.0V (2ohm), 28.3V (4ohm)
Mono-bridge output 200W (4ohm, 8ohm, 16ohm, the sinusoidal succession minimum mean-value power output)
Output RMS voltage: 28.3V (4ohm), 40.0V (8ohm), 56.6V (16ohm)
THD 0.5% or less (being all the level in 250mW - an Output power)
Intermodulation distortion (SMPTE) 0.5% or less (when peaking capacity does not exceed the twice of a rated power output at the moment)
Output-power frequency 20Hz - 20kHz
Frequency characteristic 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio (A load) 100dB (below an Output power)
Wide band dumping factor 18 or more
Output load impedance Stereo: 2 ohms, 4ohm, 8ohm
Mono-parallel: 1 ohm, 2ohm, 4ohm
Mono-bridge: 4 ohms, 8ohm, 16ohm
Input impedance Unbalance: 20kohm
Balance: 40kohm
Input sensitivity 1.0V
Valves employed 12AX7x4 (an input and phase inversion)
12AT7x4 (a voltage amplification and driver)
KT88 or 6550x8 (output tube)
Power source AC100V, 50Hz/60 Hz, 5.8A
Dimensions Width 455.4x height 257.2x depth of 406.4mm
Weight 40kg
