器材规格
Form Stereo power amplifier
Output power
stereo: 120W+120W
15.5Vrms (at the time of a 2-ohm load intensity)
21.9Vrms (at the time of a 4-ohm load intensity)
31.0Vrms (at the time of an 8-ohm load intensity)
43.8Vrms (at the time of a 16-ohm load intensity)
mono: 240W
15.5Vrms (at the time of a 1-ohm load intensity)
21.9Vrms (at the time of a 2-ohm load intensity)
31.0Vrms (at the time of a 4-ohm load intensity)
43.8Vrms (at the time of an 8-ohm load intensity)
Output load impedance stereo: 2 ohm, 4ohm, 8ohm, 16ohm
mono: 1 ohm, 2ohm, 4ohm, 8ohm
Output-power band 20Hz - 20kHz
THD 0.1% or less (at the time of Outputs 0.25W-120W, 20Hz - 20kHz, and both channel operation)
Cross modulation distortion 0.1% or less (at the time of an Output power)
Frequency characteristic
(at the time of 1W output) 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio 95dB or more (at the time of an Output power)
Output voltage 25V
Dumping factor stereo: 16 (2ohm), 50 (4ohm), 20 (8ohm), 14 (16ohm)
mono: 16 (1ohm), 50 (2ohm), 20 (4ohm), 14 (8ohm)
Input sensitivity/impedance 0.75V, 2.5V (switching type) / 100kohm
The semiconductor used Silicon transistor: 45 pieces
IC: Eight pieces
Silicon diode: 45 pieces
Supply voltage AC120V, 50Hz/60Hz
Power consumption 50W (at the time of a non-signal)
460W (at the time of a maximum rating output)
Dimensions Main unit: Width 381x height 127x depth of 330.2mm
Front panel: Width 406.4x138.1mm in height
Weight 29.5kg (net)
35.0kg (at the time of an original packaging)
Output power
stereo: 120W+120W
15.5Vrms (at the time of a 2-ohm load intensity)
21.9Vrms (at the time of a 4-ohm load intensity)
31.0Vrms (at the time of an 8-ohm load intensity)
43.8Vrms (at the time of a 16-ohm load intensity)
mono: 240W
15.5Vrms (at the time of a 1-ohm load intensity)
21.9Vrms (at the time of a 2-ohm load intensity)
31.0Vrms (at the time of a 4-ohm load intensity)
43.8Vrms (at the time of an 8-ohm load intensity)
Output load impedance stereo: 2 ohm, 4ohm, 8ohm, 16ohm
mono: 1 ohm, 2ohm, 4ohm, 8ohm
Output-power band 20Hz - 20kHz
THD 0.1% or less (at the time of Outputs 0.25W-120W, 20Hz - 20kHz, and both channel operation)
Cross modulation distortion 0.1% or less (at the time of an Output power)
Frequency characteristic
(at the time of 1W output) 20Hz-20kHz+0 -0.25 dB
10Hz-100kHz+0 -3.0 dB
SN ratio 95dB or more (at the time of an Output power)
Output voltage 25V
Dumping factor stereo: 16 (2ohm), 50 (4ohm), 20 (8ohm), 14 (16ohm)
mono: 16 (1ohm), 50 (2ohm), 20 (4ohm), 14 (8ohm)
Input sensitivity/impedance 0.75V, 2.5V (switching type) / 100kohm
The semiconductor used Silicon transistor: 45 pieces
IC: Eight pieces
Silicon diode: 45 pieces
Supply voltage AC120V, 50Hz/60Hz
Power consumption 50W (at the time of a non-signal)
460W (at the time of a maximum rating output)
Dimensions Main unit: Width 381x height 127x depth of 330.2mm
Front panel: Width 406.4x138.1mm in height
Weight 29.5kg (net)
35.0kg (at the time of an original packaging)
