器材规格
Form Stereo power amplifier
Output
(sinusoidal consecutive output) stereo: 600W+600W (2ohm, 4ohm, 8ohm)
mono: 1,200W (1ohm, 2ohm, 4ohm, 8ohm, 16ohm)
Output load impedance stereo: 2 ohm, 4ohm, 8ohm
mono parallel: 1 ohm, 2ohm, 4ohm
mono bridge: 4ohm, 8ohm, 16ohm
Output frequency band 20Hz - 20kHz
THD
(20Hz - 20kHz) stereo: 0.005% or less (250mW-600W, both channel operation)
mono: 0.005% or less (250mW-1200W)
Cross modulation distortion
(20Hz - 20kHz) stereo: 0.005% or less
(It is about a single-sided channel at the less than peek 1,200W and both of channel operations time. )
mono: 0.005% or less (a peek and less than 2,400W)
Frequency band
(at the time of 1W output) 20Hz-20kHz+0 -0.26 dB
10Hz-100kHz+0 -3 dB
SN ratio 105dB or less (at the time of an Output power A Wei Ted)
IHF dynamic head room 1.7dB
Dumping factor 40 or more
Input impedance 20kohms (unbalance)
40kohms (equilibrium)
Input sensitivity 1.4V and 2.5V switching
Power guarding It is less than THD2% to over-drive 14dB at 1kHz.
An attached functionality The power meter of an illumination with a voltage regulator
The meter window changeover switch of WATTS/HOLD
Right-and-left independent gain volume
Headphone monitor termination
Speaker on/off switchpoint
Power source AC100V, 50Hz/60 Hz, 2A-24.5A and 15A, Underwriters Laboratories/CSA
Dimensions Width 483x height 267x depth of 457mm (termination included)
Handle path clearance 44mm
Weight 59kg
Output
(sinusoidal consecutive output) stereo: 600W+600W (2ohm, 4ohm, 8ohm)
mono: 1,200W (1ohm, 2ohm, 4ohm, 8ohm, 16ohm)
Output load impedance stereo: 2 ohm, 4ohm, 8ohm
mono parallel: 1 ohm, 2ohm, 4ohm
mono bridge: 4ohm, 8ohm, 16ohm
Output frequency band 20Hz - 20kHz
THD
(20Hz - 20kHz) stereo: 0.005% or less (250mW-600W, both channel operation)
mono: 0.005% or less (250mW-1200W)
Cross modulation distortion
(20Hz - 20kHz) stereo: 0.005% or less
(It is about a single-sided channel at the less than peek 1,200W and both of channel operations time. )
mono: 0.005% or less (a peek and less than 2,400W)
Frequency band
(at the time of 1W output) 20Hz-20kHz+0 -0.26 dB
10Hz-100kHz+0 -3 dB
SN ratio 105dB or less (at the time of an Output power A Wei Ted)
IHF dynamic head room 1.7dB
Dumping factor 40 or more
Input impedance 20kohms (unbalance)
40kohms (equilibrium)
Input sensitivity 1.4V and 2.5V switching
Power guarding It is less than THD2% to over-drive 14dB at 1kHz.
An attached functionality The power meter of an illumination with a voltage regulator
The meter window changeover switch of WATTS/HOLD
Right-and-left independent gain volume
Headphone monitor termination
Speaker on/off switchpoint
Power source AC100V, 50Hz/60 Hz, 2A-24.5A and 15A, Underwriters Laboratories/CSA
Dimensions Width 483x height 267x depth of 457mm (termination included)
Handle path clearance 44mm
Weight 59kg
