器材规格
Form Tube preamplifier
Gain (1kHz) Low gain RIAA input: 49dB
High gain RIAA input: 65dB
Play bandwidth 5Hz - 88kHz (at the time of no-load)
5.5Hz - 83kHz (at the time of 50kohm load)
5.5Hz - 50kHz (at the time of 50kohm and 1000pF load)
Signal to noise ratio (100mV)
1kHz input standard - 86dB (400Hz - 80kHz, input short-circuit)
- 83dB (20hz-80kHz, input short-circuit)
THD 0.18% (at the time of 1Vrms output 1kHz)
RIAA deflection 40Hz-22kHz±0.05dB
Rise time 4microsec (at the time of no-load)
7microsec (at the time of 1000pF load)
Maximum except take-off 30V (peak)
Dimensions Main part: Width 483x height 64x depth of 297mm
Power source: Width 105x height 110x depth of 293mm
Weight Main part: 4.7kg
Power source: 3.4kg
Gain (1kHz) Low gain RIAA input: 49dB
High gain RIAA input: 65dB
Play bandwidth 5Hz - 88kHz (at the time of no-load)
5.5Hz - 83kHz (at the time of 50kohm load)
5.5Hz - 50kHz (at the time of 50kohm and 1000pF load)
Signal to noise ratio (100mV)
1kHz input standard - 86dB (400Hz - 80kHz, input short-circuit)
- 83dB (20hz-80kHz, input short-circuit)
THD 0.18% (at the time of 1Vrms output 1kHz)
RIAA deflection 40Hz-22kHz±0.05dB
Rise time 4microsec (at the time of no-load)
7microsec (at the time of 1000pF load)
Maximum except take-off 30V (peak)
Dimensions Main part: Width 483x height 64x depth of 297mm
Power source: Width 105x height 110x depth of 293mm
Weight Main part: 4.7kg
Power source: 3.4kg
