器材规格
Form Stereo preamplifier
Input sensitivity/impedance 0.125mV/100 ohms
Maximum permissible input (1kHz) 19mV
THD (20Hz - 20kHz) 0.002% or less
Frequency response (RIAA deflection) 10Hz-100kHz±0.2dB
Signal to noise ratio 76dB (input conversion noise level 154dBV)
Input sensitivity/impedance 2.5mV/50kohm
* The change to 100 ohms is possible for Phono2.
Maximum permissible input (1kHz) 380mV
Maximum except take-off 23V
Output power 150mV
THD 0.002% or less (at the time of 20Hz - 20kHz, and 2V output)
RIAA deflection 10Hz-100kHz±0.2dB
Signal to noise ratio (IHF-A weight) ±380v/microsec
Separation 1kHz [ 20Hz - ] : 80dB or more
20kHz : 70dB or more
Gain 35.6dB(1kHz)
Input sensitivity/impedance Tuner, Aux, DAD, Tape1, 2:150mV/50kohm
Output power 1.5V
THD 0.002% or less (at the time of 20Hz - 20kHz, and 5V output)
Frequency response 2Hz-300kHz+0 -3 dB
10Hz-100kHz+0 -0.3 dB
Signal to noise ratio (IHF-A weight) 100dB
Separation
At the time of the Volume maximum 1kHz [ 20Hz - ] : 100dB
20kHz:75dB
At the time of Volume-20dB 1kHz [ 20Hz - ] : 100dB
20kHz:75dB
Tone control Turnover frequency: 125Hz/2 kHz, 125Hz/8 kHz, 500Hz/2 kHz, 500Hz/eight kHz
Increase and decrease of point: ±0.5dB, ±1.0dB, ±2.0dB, ±4.0dB, ±8.0dB
(with the frequency of 20Hz, and 20kHz)
Muting - infinity (a Muting display blinks)
Subsonic Filter 16Hz, 12 dB/oct
20Hz, 6 dB/oct
The main use parts Transistor: 171 pieces
FET: 80 pieces
IC: 11 pieces
Diode: 123 pieces
Rectification stack: One piece
Reed relay: Eight pieces
Relay: Two pieces
Power supply voltage AC100V, 50Hz/60Hz
AC outlet Power-switch linkage: Three lines, Total 210W
Power-switch un-interlocking.: Two lines, Total 700W
Power consumption 90W
Dimensions Width 455x height 134x depth of 392mm (it is an included about the height of knobs and a base)
Weight 14.3kg
Attachment Low capacity connecting cord
Input sensitivity/impedance 0.125mV/100 ohms
Maximum permissible input (1kHz) 19mV
THD (20Hz - 20kHz) 0.002% or less
Frequency response (RIAA deflection) 10Hz-100kHz±0.2dB
Signal to noise ratio 76dB (input conversion noise level 154dBV)
Input sensitivity/impedance 2.5mV/50kohm
* The change to 100 ohms is possible for Phono2.
Maximum permissible input (1kHz) 380mV
Maximum except take-off 23V
Output power 150mV
THD 0.002% or less (at the time of 20Hz - 20kHz, and 2V output)
RIAA deflection 10Hz-100kHz±0.2dB
Signal to noise ratio (IHF-A weight) ±380v/microsec
Separation 1kHz [ 20Hz - ] : 80dB or more
20kHz : 70dB or more
Gain 35.6dB(1kHz)
Input sensitivity/impedance Tuner, Aux, DAD, Tape1, 2:150mV/50kohm
Output power 1.5V
THD 0.002% or less (at the time of 20Hz - 20kHz, and 5V output)
Frequency response 2Hz-300kHz+0 -3 dB
10Hz-100kHz+0 -0.3 dB
Signal to noise ratio (IHF-A weight) 100dB
Separation
At the time of the Volume maximum 1kHz [ 20Hz - ] : 100dB
20kHz:75dB
At the time of Volume-20dB 1kHz [ 20Hz - ] : 100dB
20kHz:75dB
Tone control Turnover frequency: 125Hz/2 kHz, 125Hz/8 kHz, 500Hz/2 kHz, 500Hz/eight kHz
Increase and decrease of point: ±0.5dB, ±1.0dB, ±2.0dB, ±4.0dB, ±8.0dB
(with the frequency of 20Hz, and 20kHz)
Muting - infinity (a Muting display blinks)
Subsonic Filter 16Hz, 12 dB/oct
20Hz, 6 dB/oct
The main use parts Transistor: 171 pieces
FET: 80 pieces
IC: 11 pieces
Diode: 123 pieces
Rectification stack: One piece
Reed relay: Eight pieces
Relay: Two pieces
Power supply voltage AC100V, 50Hz/60Hz
AC outlet Power-switch linkage: Three lines, Total 210W
Power-switch un-interlocking.: Two lines, Total 700W
Power consumption 90W
Dimensions Width 455x height 134x depth of 392mm (it is an included about the height of knobs and a base)
Weight 14.3kg
Attachment Low capacity connecting cord
