器材规格
Form Channel dividing amplifier
Splitting band L channel: 220Hz or less
M channel: 220Hz - 1kHz
MH channel: 1kHz - 5kHz
H channel: 5kHz or more
Cross-over-frequency deflection Less than ±4%
Damping characteristics 18dB/oct
Passage belt gain - 1dB (M, MH, and H channel are with an output regulator)
Input impedance 50kohm
Output load impedance 300ohms or less (at the time M,MH,H channel of an output maxima)
Maximum permissible input 3Vrms
Distortion 0.15% or less (at the time of 1V input)
S/N ratio 90dB or more (each channel input 1 V:00)
Power source AC100V, 50Hz/60Hz
Power consumption About 1.5 VA
Splitting band L channel: 220Hz or less
M channel: 220Hz - 1kHz
MH channel: 1kHz - 5kHz
H channel: 5kHz or more
Cross-over-frequency deflection Less than ±4%
Damping characteristics 18dB/oct
Passage belt gain - 1dB (M, MH, and H channel are with an output regulator)
Input impedance 50kohm
Output load impedance 300ohms or less (at the time M,MH,H channel of an output maxima)
Maximum permissible input 3Vrms
Distortion 0.15% or less (at the time of 1V input)
S/N ratio 90dB or more (each channel input 1 V:00)
Power source AC100V, 50Hz/60Hz
Power consumption About 1.5 VA
