                    器材规格
                    	A – Distance from pivot to stylus 233.15mm
B – Distance from pivot to turntable centre 215.35mm
C – Cartridge fixing centres 12.70mm
D – Offset angle 23.635°
E – Linear offset 93.47mm
F – Overhang 17.8mm
G – Height above mounting surface max. 87.90mm
min. 56.40mm
H – Height of record surface above mounting surface max. 57.90mm
min. 26.40mm
J – Depth below mounting surface 56.75mm
K – Radial clearance for balance weight 73.0mm
L – Clearance between cabinet lid and record surface assuming cartridge height at 17.0mm 3
                B – Distance from pivot to turntable centre 215.35mm
C – Cartridge fixing centres 12.70mm
D – Offset angle 23.635°
E – Linear offset 93.47mm
F – Overhang 17.8mm
G – Height above mounting surface max. 87.90mm
min. 56.40mm
H – Height of record surface above mounting surface max. 57.90mm
min. 26.40mm
J – Depth below mounting surface 56.75mm
K – Radial clearance for balance weight 73.0mm
L – Clearance between cabinet lid and record surface assuming cartridge height at 17.0mm 3
