器材规格
格式Format: 座地偶极3°向后倾斜Floor standing dipole with 3° fixed tilt black
种类Type 静电式全频发声Multiple Electrostatic Drive Membranes
静电片数量No. of Panel Elements 6
延迟Time Delay 循序同轴电极环Progressive Concentric Rings
底盘结构Chassis Structure 强力铝/钢合成Heavy Duty Composite Aluminium / Steel
ACOUSTIC PERFORMANCE
最大输出Maximum Output 2 N/㎡ at 2m on axis
灵敏度Sensitivity 1.5 mbar per volt referred to 1m
(86dB/2.83V RMS equivalent)
阻抗Impedance 8 Ohms nominal
阻抗变动Impedance Variation 4 - 20 Ohms
最大输入Maximum Input Continuous input voltage (RMS): 10V
Programme Peak for undistorted output: 40V
Permitted peak input: 55V
频率响应Frequency Reponse 32Hz - 21kHz (-6dB)
28Hz - 23kHz (useable)
Directivity Index See Polar Diagrams
失真率Distortion (100dB @ 1M) Above 1000Hz 0.15%
Above 100Hz 0.5%
Above 50Hz 1.0%
Directivity Index See Polar Diagrams
ELECTRICAL
电源AC Input 交流电220 - 240V or 110-120V or 100V
保险丝Power Fuse 63 mA anti-surge, 200-240V
100 mA anti-surge, 100-120V
GENERAL
耗电量Power Consumption 6W
尺寸Dimension (H × W × D) 1470 × 690× 380 (mm)
净重Net Weight 44kg eachNote:The right is reserved to alter performance, specification and appearance as required
¥115000/对
种类Type 静电式全频发声Multiple Electrostatic Drive Membranes
静电片数量No. of Panel Elements 6
延迟Time Delay 循序同轴电极环Progressive Concentric Rings
底盘结构Chassis Structure 强力铝/钢合成Heavy Duty Composite Aluminium / Steel
ACOUSTIC PERFORMANCE
最大输出Maximum Output 2 N/㎡ at 2m on axis
灵敏度Sensitivity 1.5 mbar per volt referred to 1m
(86dB/2.83V RMS equivalent)
阻抗Impedance 8 Ohms nominal
阻抗变动Impedance Variation 4 - 20 Ohms
最大输入Maximum Input Continuous input voltage (RMS): 10V
Programme Peak for undistorted output: 40V
Permitted peak input: 55V
频率响应Frequency Reponse 32Hz - 21kHz (-6dB)
28Hz - 23kHz (useable)
Directivity Index See Polar Diagrams
失真率Distortion (100dB @ 1M) Above 1000Hz 0.15%
Above 100Hz 0.5%
Above 50Hz 1.0%
Directivity Index See Polar Diagrams
ELECTRICAL
电源AC Input 交流电220 - 240V or 110-120V or 100V
保险丝Power Fuse 63 mA anti-surge, 200-240V
100 mA anti-surge, 100-120V
GENERAL
耗电量Power Consumption 6W
尺寸Dimension (H × W × D) 1470 × 690× 380 (mm)
净重Net Weight 44kg eachNote:The right is reserved to alter performance, specification and appearance as required
¥115000/对
